Ubiquiti UniFi Switch 48 US-48 (NON-POE)
Ubiquiti UniFi Switch 48 US-48 (NON-POE)
The US-48 (NON POE) UniFi Switch is a fully managed forty-eight port switch that delivers robust performance, intelligent switching for growing networks. The US-48 delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
Ubiquiti UniFi Switch US-48 Key Features
- 48 Gigabit RJ45 Ports
- 2 SFP+ Ports
- 2 SFP Ports
- 1 Serial Console Port
- Non-Blocking Throughput: 70 Gbps
- Switching Capacity: 140 Gbps
- Forwarding Rate: 104.16 Mpps
- Maximum Power Consumption: 56W
Switching Performance
The UniFi Switch US-48 offers the forwarding capacity to simultaneously process traffic on all ports at line rate withoutany packet loss. For its total, non‑blocking throughput, the Ubiquiti UniFi Switch 48 model supports up to 70 Gbps.
Fiber Connectivity
The Ubiquiti UniFi Switch 48 adds two SFP+ports for high-capacity uplinks of up to 10 Gbps, so you can directly connect to a high‑performance storage server or deploy a long‑distance uplink to another switch.
Ubiquiti UniFi Switch US-48 - Technical Specifications
General
- Dimensions 443 x 43 x 286 mm (17.44 x 1.69 x 11.26")
- Weight -
Rack-Mount Brackets Excluded - 3.56 kg (7.85 lb)
Rack-Mount Brackets Included - 3.65 kg (8.06 lb) - Networking Interfaces
(48) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1/10 Gbps SFP+ Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports - Management Interface (1) RJ45 Serial Port Out-of-Band, Ethernet In-Band
- Total Non-Blocking Throughput 70 Gbps
- Switching Capacity 140 Gbps
- Forwarding Rate 104.16 Mpps
- Power Method 100-240VAC/50-60 Hz, Universal Input
- Power Supply AC/DC, Internal, 56W DC
- Max. Power Consumption 56W
- LEDs per Port Speed/Link/Activity
- Sound Level
Fan Level: 0 - 34 dBa
Fan Level: 1 - 37 dBa - ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
- Rack Mount Yes, 1U High
- Shock and Vibration ETSI300-019-1.4 Standard
- Operating Temperature -5 to 40° C (23 to 104° F)
- Operating Humidity 5 to 95% Noncondensing
- Certifications CE, FCC, IC
