Grandstream GXP1625 HD IP Phone
![Grandstream GXP1625 HD IP Phone]()
![Grandstream GXP1625 HD IP Phone]()
Grandstream GXP1625 HD IP Phone
Available:In Stock
£52.20
Grandstream GXP1620/GXP1625 Datasheet (PDF)
Grandstream GXP1625 HD IP Phone
The Grandstream GXP1625 is an IP Phone that is perfect for small businesses. Professionals can enjoy HD audio on both speakerphone and handset and a clear 132 x 48 backlit graphical LCD display. Other great features include 2 SIP accounts and 3 XML programmable context-sensitive soft keys.
Grandstream GXP1625 Key Features:
- 2 SIP accounts, 2 line keys, 3-way conferencing, 3 XML programmable context-sensitive soft keys
- Dual-switched 10/100 Mbps ports, integrated PoE on GXP1625
- HD audio on speakerphone and handset
This model differs from the GXP1620 by offering integrated PoE. This feature among others allows the GXP1625 to be a versatile, user-friendly and high-quality IP office phone.
Grandstream GXP1625 Technical Specification
Protocols/Standards
- SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A re- cord, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP, CDP/SNMP/RTCP-XR
Network Interfaces
- Dual switched auto-sensing 10/100 Mbps Ethernet ports, integrated PoE (GXP1625 only)
Graphic Display
- 132 x 48 backlit graphical LCD Display
Feature Keys
- 2 line keys with dual-colour LED and 2 SIP accounts
- 3 XML programmable content sensitive soft keys
- 5 navigation menu keys
- 13 dedicated function keys for:
-Mute
-Headset
-Transfer
-Conference
-Send
-Redial
-Speakerphone
-Message
-Hold
-Page/Intercom
-Record
-Home
Voice Codecs
- Support for G.711µ/a, G.722 (wide-band), G.723, G.726-32, G.729 A/B, iLBC, inband and out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC
Telephony Features
- Hold, transfer, forward (unconditional/no-answer/busy), 3-way conferencing, call park/pickup, shared-call appearance (SCA) / bridged-line-appearance (BLA), Down- loadable phone book (XML, LDAP, up to 1000 items), call waiting, call history (up to 200 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot desking, personalized music ringtones, server redundancy & fail-over
Headset Jack
- RJ9 headset jack (allowing EHS with Plantronics headsets)
HD Audio
- Yes, HD Handseet and speakerphone with support for wideband audio.
QoS
- Layer 2 QoS (802.1Q, 802.1P)
- Layer 3 QoS (ToS, DiffServ, MPLS)
Security
- User and administrator access control
- MD5 and MD5-sess based on authentication
- 256-bit AES encrypted configuration file
- TLS
- SRTP
- HTTPS
- 802.1x media access control
Multi-Language
- English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, simpli- fied and traditional Chinese, Korean, Japanese and more
Upgrade/Provisioning
- Firmware upgrade via TFTP / HTTP / HTTPS, mass provisioning using TR-069 or AES encrypted XML configuration file, FTP/FTPS
Power & Green Energy Efficiency
- Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA; PoE: IEEE802.3af Class 2, 3.84W-6.49W; IEEE802.3az (EEE) (GXP1625 only)
Physical
- Dimension - 209mm (L) x 184.5mm (W) x 76.2mm (H) (with handset)
- Unit Weight - 0.73kg
- Package Weight - 1.1kg
Temperature and Humidity
- Operation: 0°C to 40°C, Storage: -10°C to 60°C , Humidity: 10% to 90% Non-condensing
Package Content
- GXP1620 phone, handset with cord, base stand, network cable, Quick installation guide, brochure and GPL License
Compliance
- FCC: Part 15 (CFR 47) Class BCE : EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 60950.1
