Digium 1A8B04F 8 port modular analog PCI-Express x1 card with 4 FXS and 4 FXO interfaces and HW Echo Can
![Digium 1A8B04F 8 port modular analog PCI-Express x1 card with 4 FXS and 4 FXO interfaces and HW Echo Can]()
![Digium 1A8B04F 8 port modular analog PCI-Express x1 card with 4 FXS and 4 FXO interfaces and HW Echo Can]()
Digium 1A8B04F - Technical Specifications
Digium 1A8B04F 8 port modular analog PCI-Express x1 card with 4 FXS and 4 FXO interfaces and HW Echo Can
Available:In Stock
£1,156.44
Digium 1A8B04F 8 port modular analog PCI-Express x1 card with 4 Station and 4 Trunk interfaces and HW Echo Can
The Digium 1A8B04F 8 Port Analog Card supports 8 connections in an Asterisk System.
Digium 1A8B04F Key Applications
- Connect Asterisk-based systems to analog phone lines
- Connect analog PBX systems to VoIP services
- Channel Bank Replacement / Alternative
- Gateway Termination to analog telephones/lines
- Suitable for Small Office/Home Office (SOHO) and Small and Medium Business (SMB) applications
The 1A8B04F is compatible with all versions of Asterisk using the DAHDI driver framework.
Digium 1A8B04F - Technical Specifications
General
- One (1) - eight (8) analog ports
- PCI or PCI Express bus architectures
- Combine line (FXO) and station (FXS) modules
- Accepts up to two (2) quad-port modules or up to 4 single-port modules
- Optional DSP -based carrier grade echo cancellation module
- 32-bit 33MHz
- Loop Start or Kewl Start Signaling
- Temperature: 0° to 50° C
- Digium patented VoiceBus™ technology for better audio
- 30-day 100% satisfaction money back guarantee
- 5-year warranty
- With Asterisk - DAHDI 2.7 or later required
- With Switchvox - Switchvox 5.8.1 or later required (Coming soon)
|
|
