Netgear ProSafe GS752TP, 48 x 10/100/1000 Mbps, PoE, 1000base-T, 4 x SFP
![Netgear ProSafe GS752TP, 48 x 10/100/1000 Mbps, PoE, 1000base-T, 4 x SFP]()
![Netgear ProSafe GS752TP, 48 x 10/100/1000 Mbps, PoE, 1000base-T, 4 x SFP]()
Netgear ProSafe GS752TP, 48 x 10/100/1000 Mbps, PoE, 1000base-T, 4 x SFP
Available:In Stock
£895.44
Netgear ProSafe GS752TP, 48 x 10/100/1000 Mbps, PoE, 1000base-T, 4 x SFP
The Netgear ProSafe GS752TP, 48 x 10/100/1000 Mbps, PoE, 1000base-T, 4 x SFP offers powerful L2 and L2+ features, better PoE functionality, and enhanced performance and usability. They are purposely designed for converged networks where voice, video, data are all carried on a single network platform. These switches are optimized for network efficiency, operational cost savings, and ease of management. .
Features of Netgear ProSafe GS752TP
- PoE and PoE+ Support available for all configurations
- Auto Voice VLAN for fast and reliable deployment of VoIP
- Auto Video VLAN, following the same concept of Auto Voice, help speed up your deployment of IP-based surveillance systems
- Static routing, helps route internal traffic for more efficient use of network resources
- IGMP and MLD snooping, provides advanced multicast filtering
Netgear ProSafe GS752TP - Technical Specifications
General
- RJ45 Ports Qty 48
- PoE Ports Qty 48
- SFP Ports Qty 4
- Mounting Rackmount
- Switch Speed Gigabit
- PoE Yes
- Stackable No
- Management Smart Managed
Bandwidth
- Full duplex Yes
Certificates
- Safety CE, CSA, UL
- Electromagnetic compatibility CE, FCC, Class A EN 55022, Class A C-Tick, EN 50082-1, EN 55024, CCC
Colour
- Colour of product Grey
Connectivity
- SFP ports quantity 4
- Basic switching RJ-45 Ethernet ports type Gigabit 10/100/1000
- Basic switching RJ-45 Ethernet ports quantity 48
Data transmission
- Switching capacity 1 Gbit/s
- Number of static routes 32
Endurance
- Mean time between failures (MTBF) 220447 h
Energy management
- Power consumption (typical) 384 W
- Power over Ethernet (PoE) support Yes
Illumination/Alarms
- LED indicators Yes
Management features
- Switch layer L3
- Web-based management Yes
- Switch type Managed
- Firmware upgradeable Yes
- VLAN support Yes
Memory
- Packet buffer memory 8 MB
Networking
- Supported network protocols IPv4, IPv6, TFTP, SNTP, TACACS+
- MAC address table 8000 entries
- Networking standards IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
- Quality of Service (QoS) support Yes
- Port mirroring Yes
- Jumbo frames support Yes
- Multicast support Yes
- Broadcast storm control Yes
- Rate limiting Yes
- DHCP client Yes
- IGMP snooping Yes
- Number of VLANs 256
- Spanning tree protocol Yes
- Fiber optic connector SFP
- Copper ethernet cabling technology 1000BASE-T, 100BASE-T, 10BASE-T
Operational conditions
- Operating altitude 0 - 3000 m
- Operating relative humidity range 10 - 90 %
- Storage temperature range (T-T) -20 - 70 °C
- Operating temperature range (T-T) 0 - 55 °C
- Storage relative humidity range 0 - 95 %
Other features
- Power LED Yes
Packaging content
- Cables included AC
- User guide Yes
Power over Ethernet (PoE)
- Power over Ethernet (PoE) ports quantity 48
- Power over Ethernet plus (PoE+) ports quantity 8
- Total Power over Ethernet (PoE) budget 15.4 W
Protocols
- Management protocols IGMP, SNMP v1/v2/v3, RMON 1/2/3/9, SSL/HTTPS & TLS v1.0
Security
- MAC address filtering Yes
- Static port security Yes
- Access Control List (ACL) Yes
Technical details
- Rack mounting Yes
- Heat dissipation 1750.70 BTU/h
- Source data-sheet Icecat.biz
Technical details
- Weight 5.1 kg
- Height 43 mm
- Width 440 mm
- Depth 316 mm
Manufacturer Information
- Manufacturer Netgear
- EAN 0606449089882
