Citronic D4350 Quad Digital Power Amplifier 4 x 350W 4-8 Ohms
- Category:Best selling products,Commercial Audio,Low Impedance Power Amplifiers,New products,Pro Amplifiers
D-series Quad Power Amplifiers
Quad digital power amplifier in a lightweight 1U rack-mountable format. An energy-efficient switch-mode power section and class-D amplifiication circuit delivers accurate power-on-demand to four independent speaker outputs. Proprietary cool guide technology provides stable temperature management for dependable operation. Each pair of output channels can be separately parallel switched or bridged as a full or part stereo amplifier configuration. For channel A, there is a switchable 120Hz low-pass filter for use with subwoofers and a channels C and D have a switchable stereo pair of 120Hz high pass filters to effectively focus power in full-range cabs operating as mid-tops in conjunction with sub-woofers. For permanent or mobile installations, the D-series offers an invaluable and flexible problem solver for audio designers and sound engineers.
- Switchable bridge or parallel mono modes
- Switchable high and low pass filters
- Configurable as a quad, stereo or 2.1 system
- Fully balanced audio signal path
- Full audio and power protection with peak limiter
- Output : rms @ 4 Ohms4 x 350W
- Output : rms @ 8 Ohms4 x 200W
- Bridge power @ 8 Ohms2 x 700W (both pairs of channels bridged)
- Weight5.083kg
- Power supply220-240Vac, 50/60Hz (IEC)
- Modes2 x Stereo, Parallel (mono), Bridge (mono)
- Input sensitivity0dB = 0.775Vrms
- CrossoverInput A 120Hz LPF and C+D 120Hz HPF (all switchable)
- Input connections4 x XLR female
- Sound output4 x SPK connectors
- Dimensions482 x 248 x 44mm (without feet)
Trade Information
- SKU172.144UK
- Barcode EAN5015972232088
- Tariff code8518500090
- Country of originChina (CN)
- Packaging typeGift Box
- Package dims95 x 370 x 535mm
- Package quantity1 unit
- Nett weight4.8700kg
- Gross weight5.4500kg
- Carton dims205 x 375 x 545mm
- Carton quantity5 units
- Carton weight28.60kg
