Aruba Instant On 1930 48G 4SFP+ Switch (JL685A)
- Category:Aruba Instant On 1930 Switch Series,Aruba Switches,Best selling products,Network Switches,New products
Aruba Instant On 1930 48G 4SFP+ Switch (JL685A)
The Aruba Instant On 1930 48G 4SFP+ Switch (JL685A) is a 48G 4SFP/SFP+ switch.
The Aruba Instant On 1930 switches are advanced, smart-managed, fixed configuration Gigabit switches designed for small businesses that are easy-to-deploy and affordable. They’re made to handle today’s bandwidth-heavy applications like voice and video conferencing, enabling consistent connectivity to enhance performance.
Instant On 1930 48G 4SFP+ Switch (JL685A) Key Features
- Plug and Play
- 48 RJ-45 autosensing 10/100/1000 ports
- 4 dedicated 1G/10G SFP+ fiber ports
- Smart-managed layer 2+ Ethernet
- Security controls
- Convenient mobile app
Easy set up and management
The Aruba Instant On mobile app allows you to set up, manage, and monitor Instant On switches and access points directly from your phone. Within the app, you get guided step-by-step instructions to install Instant On devices to get your network up and running quickly – no technical expertise required. And cloud-based access allows you to access the network from anywhere, at any time.
Automatic detection
Instant On automatically detects and applies highest (critical) PoE priority to Instant On Access Points for uninterrupted power delivery and wireless network access. Wired and wireless voice traffic is prioritized with high QoS priority end-to-end for optimal voice performance.
Non-Intrusive, aesthetic design
Aruba Instant On switches are designed to complement the sleek and clean look of the Instant On access points, and to blend discreetly into your site’s environment.
Customisable features
Customisable features include basic Layer 2 features like VLANs and link aggregation, as well as advanced features such as Layer 3 IPv4 static routing, ACLs, and Spanning Tree Protocols, and IPv6 Host mode.
Instant On mobe app optimises user experience
The Aruba Instant On mobile app provides common workflows for Instant On switches and access points making it easier to configure, monitor and manage your network remotely without the need for additional hardware like cloud keys or VPN. You can also update firmware on your Instant On devices directly from the cloud whenever you want, from wherever you are.
I/O ports and slots
- 48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASET/100BASE
- 4 SFP+ 1/10GbE ports
Physical Characteristics
- Dimensions: 17.42(w) x 11.12(d) x 1.73(h) in (44.25 x 28.24 x 4.39 cm) (1U height)
- Weight: 6.91 lb (3.13 kg)
Memory and processor
- ARM Cortex-A9 @ 800 MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5 MB
Performance
- 100 Mb Latency: < 4.5 uSec, packet size: 64B
- 1000 Mb Latency: < 2.2 uSec, packet size: 64B
- 10000 Mb Latency: < 1.2 uSec, packet size: 64B
- Throughput (Mpps): 130.95 Mpps, packet size: 64B
- Switching capacity: 176 Gbps
- Routing Table size (# of static entries): 32 static entries
- MAC Address table size (# of entries): 16,000 entries
- Reliability MTBF (years): 114
Environment
- Operating temperature: 32°F to 104°F (0°C to 40°C)
- Operating relative humidity: 15% to 95% @ 104°F (40°C)
- Nonoperating/Storage temperature: -40°F to 158°F (-40°C to 70°C)
- Nonoperating/Storage relative humidity: 15% to 95% @ 140°F (60°C)
- Altitude: up to 10,000 ft (3 km)
- Acoustic: Power: 0 dB no fan
Electrical Characteristics
- Frequency: 50/60 Hz
- AC voltage: 100 - 127/200 - 240 VAC
- Current: .8/.5 A
- Maximum power rating: 36.9 W
- Idle power: 16.8 W
- Power supply: Internal power supply
Safety
- UL 60950-1
- IEC 60950-1
- EN 60950-1
- CAN/CSA-C22.2 No. 60950-1
- EN 60825-1 UL 62368-1 Ed. 2
- IEC 62368-1 Ed. 2
- EN 62368-1:2014
Emissions
- VCCI-CISPR 32, Class A
- CNS 13438
- ICES-003 Issue 6 Class A
- FCC CFR 47 Part 15, Class A
